Introduction:
1. Communication indicators:
Communication speed: 2.5Gbps;
Communication distance: 144km;
Communication range: elevation angle: 10°-60°, azimuth angle: ±85°;
Error rate: better than 0.62x10⁷;
2. Link indicators:
Laser link capture time: 10s;
Laser link tracking accuracy: 3μrad;
3. Optical indicators:
Coarse tracking field of view: 8mrad;
Signal light wavelength: 1530nm/1550nm;
Beacon light wavelength: 808nm/850nm;
4. Environmental indicators:
Working temperature: ±10℃~70℃;
Storage temperature: 0℃~85℃;
5. Volume & Power consumption:
Weight: 25kg;
Dimensions: 450mm*450mm*450mm;
Power consumption: 60W;
Features:
Communication speed: 2.5Gbps;
Communication distance: 144km;
Communication range: elevation angle: 10°-60°, azimuth angle: ±85°;
Error rate: better than 0.62x10⁷;
2. Link indicators:
Laser link capture time: 10s;
Laser link tracking accuracy: 3μrad;
3. Optical indicators:
Coarse tracking field of view: 8mrad;
Signal light wavelength: 1530nm/1550nm;
Beacon light wavelength: 808nm/850nm;
4. Environmental indicators:
Working temperature: ±10℃~70℃;
Storage temperature: 0℃~85℃;
5. Volume & Power consumption:
Weight: 25kg;
Dimensions: 450mm*450mm*450mm;
Power consumption: 60W;
Features:
Multi platform installation;
High speed, long distance, and high precision;
Fast chain building and full duplex communication;
Product applications: early warning aircraft, reconnaissance aircraft, UAVs, 2.5G peer backbone network, emergency communication/wartime communication
