To meet the needs of low and slow small UAS and aircraft take-off and landing status monitoring in complex environments, the multi-dimensional target tracking system is developed, which integrates multi-dimensional optical imaging such as
- Visible light,
- Infrared and polarization
- High-precision laser ranging,
breaking through the integrated design of optical and mechanical structures,
- high-precision dynamic tracking,
- multi-dimensional target recognition,
- and other technologies.
With
- all-weather,
- all-day
- multi-target
- long-distance
- tracking,
- ranging,
- imaging recognition
- and other functions,
real-time provide and store target coordinate
- position,
- size,
- speed
- and other parameters.
Solve the problem of
- precise tracking,
- measurement
- and identification of dynamic small targets under complex observation conditions such as
- strong light
- and haze.
It is equipped with a directional interference module to cut off the contact between the UAV and the satellite or remote control to achieve countermeasures against the UAV.
It can be used to monitor and track unmanned aerial vehicles in airports, wharves, borders, factories, large event sites and other areas.
It can be extended to all day astronomical observation and other fields.
1) Resolution: 2048×2048 (visible), infrared (640×512)
2) Tracking accuracy: 50μard
3) Ranging accuracy: 1m
4) Tracking distance: 3km
5) Azimuth rotation range: -180°~+180°;
6) Pitch rotation range: -10°~+80°;
7) Interference frequency band: 400MHz, 800MHz, 2. 4GHz, 5.8GHz
8) System weight:
